The MCI-211G is a simple and cost effective Gigabit Ethernet media industrial converter suitable for use in a wide range of factory and building automation applications. The MCI-211G features Link Fault Forwarding (LFF) in order to forward link status changes to alert remote or central management systems via the connected media.

The unit is designed for DIN rail mounting into industrial cabinets allowing simple Ethernet connections to be established between PLCs, I/O units, drives, inverters and HMIs. The dual power input makes the unit ideal in these types of application and the fault relay can be connected to an I/O unit to provide simple network management.

Designed to work in industrial environments with its IP 31 Aluminium housing and a wide temperature specification the MCI-211 is an ideal automation solution.

The Industrial Ethernet Media Converter MCI-211 is so easy to use, simply connect power to the screw terminals and plug in your RJ-45 cables. If you plan to use the fault contacts a DIP switch allows configuration whilst LEDs provide simple diagnostics if required.

Features :

Converts 10/100/1000TX to Gigabit Fibre
Flexible SFP Fibre transceiver design
Auto Fault Detection and Alarm
Fault Alert for port and power
Two way Link loss forwarding
Power redundancy with wide range input
IP-31 grade protection with wide range operating temperature
1.5 KV Hi-Pot testing passed

Technical Specification :

Gigabit Ethernet Media Converter
1 x 10/100/1000 Base-TX with Auto MDI/MDI-X function, Auto-Negotiation
1 x SFP socket with hot-swappable function for Gigabit Ethernet SFP Transceiver

Mechanical
Installation : DIN-Rail mount
Case : Aluminum alloy metal case with grade 31 of ingress protection

Note :

* Unit tanpa PSU, karena produk industrial dan tanpa modul SFP (option).
